Flip-Over Ball Gooseneck Hitch for 2011‐2016 Chevy/GMC 3/4 & 1 Ton (2016 models with factory threaded bolt holes use the 140/240)
The Flip-Over Ball is locked in the one-piece ball socket with a spring loaded stainless steel pin. To invert the ball, just reach into the driver side rear wheel well and rotate the actuating rod 90 degrees. This cams the retaining pin to the open position. Invert the ball and rotate the actuating rod back to its original locked position. That’s all there is to it!
- Raise or hide ball instantly with rod in rear wheel well of truck.
- Hitch ball fits in 3 hole in bed. None smaller.
- Includes spring loaded safety chain anchors.
- No welding or fabrication.
- 100% complete.
- 2-5/16 ball.
- Bolts in place using existing frame holes.
- Installs quickly without loosening bed.
- Grade 5 and 8 installation hardware provided.
- 30,000 lbs. Gross Trailer Weight.
- 7,500 lbs. Gross Tongue Weight.
Application Summary:
| Year |
Make/Model |
| 2011‐2016 |
Chevy/GMC 3/4 & 1 Ton (2016 models with factory threaded bolt holes use the 140/240) |
| Attributes |
| Category |
Towing and Accessories |
| Country of Origin (Primary) |
US |
| Emission Code |
Legal US |
| GTIN |
00819546011414 |
| Hazardous Material Code |
N |
| Life Cycle Status Code |
Available to Order |
| NAFTA Preference Criterion Code |
B |
| SDR Required Flag |
N |
| Series |
FlipOver Gooseneck Hitches |
| Subcategory |
Gooseneck Hitches and Accessories |
