Small Block Chevrolet - Gen III/IV - Adjustable Timing Pointer - Red
Upgrading to an MSD Flying Magnet Crank Trigger Kit will deliver the precise and reliable signal that a high performance engine requires. This kit gives you the ability to control timing electronically through a Holley EFI ECU (or other standalone engine management system / ignition controller). At the heart of the kit is the 3-wire Hall-Effect Sensor that is easier to set up, less susceptible to EMI/RFI interference/noise, and less likely to have false signals than other methods (Distributors and VR Magnetic Sensors). In addition, they are less prone to mechanical failure since there are no wear parts. With the included high quality timing pointer and the use of a direct bolt-on, degreed balancer (ATI 917777 or 917211), you'll be able to adjust timing in the precise increments required for your LS Engine.
Upgrading to an MSD Flying Magnet Crank Trigger Kit will deliver the precise and reliable signal that a high performance engine requires. This kit gives you the ability to control timing electronically through a Holley EFI ECU (or other standalone engine management system / ignition controller). At the heart of the kit is the 3-wire Hall-Effect Sensor that is easier to set up, less susceptible to EMI/RFI interference/noise, and less likely to have false signals than other methods (Distributors and VR Magnetic Sensors). In addition, they are less prone to mechanical failure since there are no wear parts. With the included high quality timing pointer and the use of a direct bolt-on, degreed balancer (ATI 917777 or 917211), you'll be able to adjust timing in the precise increments required for your LS Engine.
- Most accurate way to trigger your electronic fuel injection (EFI)
- Powerful magnets embedded in a 3/8” thick billet 6061-T6 aluminum trigger wheel
- 3-wire Hall-Effect Sensor that is not easily susceptible to EMI/RFI Interference
- Allows precise indexing by utilizing the 10 degree range on included timing pointer
- Easy to install much like traditional MSD Crank Trigger Kits (use with ATI Balancer - 917777 or 917211)
- Rigid mounting that will not flex and cause timing fluctuation
Information:
On some vehicles the MSD Crank Trigger Kit may require slight modifications to accommodate special engine plates, pulley systems, etc. This kit is designed to be used with the ATI Harmonic Balancer 917777 and 917211. This kit is also compatible with Meziere water pump WP333.| Attributes | |
| Brand | MSD |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category | Ignition |
| Color | Red, Red |
| Country of Origin (Primary) | US |
| Diameter | 7.25 in., 7.25 in. |
| Emission Code | 4, 4, Off Road |
| GTIN | 00090127130087 |
| Harmonized Tariff Code (Schedule B) | 8511906040 |
| Hazardous Material Code | N |
| Life Cycle Status Code | Available to Order |
| Make | Chevrolet, Chevrolet |
| NAFTA Preference Criterion Code | B |
| Operating Voltage | 5-20 Volts, 5-20 Volts |
| Product Type | Crank Trigger Kit, Crank Trigger Kit |
| SDR Required Flag | N |
| Sensor Type | Hall Effect, Hall Effect |
| Sub Category | Sensors |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 1 Year Warranty, Manufacturer's Limited 1 Year Warranty |
| part type | Ignition Crank Trigger Kit |
MSD Performance 8619 Crank Trigger Kit
Product Information
- Brand: MSD Performance
- Product Number: 8619
