Use with Pro 600 Ignition - Coil-Per-Cylinder Engines
If you've made the step up to the industry-leading MSD Pro 600 Ignition, you'll want to equip it with the best coils on the market. The Pro 600 (Capacitive Discharge Ignition) coil is the solution with the highest current and voltage available in a small compact design.
If you've made the step up to the industry-leading MSD Pro 600 Ignition, you'll want to equip it with the best coils on the market. The Pro 600 (Capacitive Discharge Ignition) coil is the solution with the highest current and voltage available in a small compact design.
- Designed for extreme racing for the Pro 600 Capacitive Discharge Ignition, PN 8000
- Supplied with hardware to mount horizontal or vertical position
- Capable of up to 50,000 Volts to ignite extreme cylinder pressures
- Over 200 millijoules of spark energy makes them ideal for use with methanol, ethanol, E85 and forced induction and power adder combinations
- Coils are designed to be mounted on Holley’s LS valve covers, or Original Equipment LS passenger car coil brackets using 72mm bolt spacing
- HEI style secondary tower for secure coil wire connection
| Attributes | |
| Bolt Spacing | 2.82-2.90 |
| Brand | MSD |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category | Ignition |
| Color | Black, Black |
| Country of Origin (Primary) | CN |
| Emission Code | 2, 4, Off Road |
| Harmonized Tariff Code (Schedule B) | 8511300080 |
| Hazardous Material Code | N |
| Inductance | 500mH |
| Inductance (mH) | 500 |
| Life Cycle Status Code | Available to Order |
| Maximum Voltage | 50,000 Volts, 50,000 |
| NAFTA Preference Criterion Code | B |
| part type | Ignition Coil |
| Peak Current | 1700 mA, 1700 |
| Primary Resistance | .064 OHMs, 0.064 |
| Product Type | Ignition Coils, Ignition Coils |
| Quantity | 8-pack, 8-pack |
| SDR Required Flag | N |
| Secondary Resistance | 466 OHMs, 466 |
| Spark Duration | 345 uS, 0.345 |
| Spark Energy | 208 mj |
| Spark Energy (mJ per spark) | 208 |
| Sub Category | Ignition Coil |
| Turns Ratio | 56:1, 2.3340277777777776 |
| Type | Drag Race / Short Duration Use, Drag Race / Short Duration Use |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 1 Year Warranty, Manufacturer's Limited 1 Year Warranty |
| GTIN | 00090127126523 |
