Universal - Use with an MSD Ignition Box

The Blaster Coil is designed to mount in most factory canister coil mounts. MSD also offers a Chrome Coil Bracket, PN 8213. It is recommended to mount the PN 8202, PN 82023, and 8223 coils in an upright position. The High Vibration Coil, PN 8222, can be mounted in any position due to its epoxy potting compound.

Improved output coil for electronic ignitions, Blaster Ignition or MSD 5, 6, and 7 Series (ballast resistor required for points)
Alkyd tower with high dielectric properties is less prone to carbon tracking
100:1 turns ratio and lower primary resistance produce high voltage output
Metal canister is filled with a premium grade oil for cooling
CARB E.O. Approved

Information:

CARB EO: D-40-37

Application Summary:

Year	Make/Model
1960-1963	American Motors Ambassador
1966-1974	American Motors Ambassador
1967-1968	American Motors American
1968-1970	American Motors AMX
1978-1979	American Motors AMX
1963-1966	American Motors Classic
1978-1979	American Motors Concord
1972-1976	American Motors Gremlin
1970-1977	American Motors Hornet
1968-1974	American Motors Javelin
1965-1967	American Motors Marlin
1971-1978	American Motors Matador
1978-1979	American Motors Pacer
1969	American Motors Rambler
1960-1961	American Motors Rebel
1967-1970	American Motors Rebel
1979	American Motors Spirit
1973-1975	Buick Apollo
1971-1973	Buick Centurion
1973	Buick Century
1960-1973	Buick Electra
1985	Buick Electra
1970-1973	Buick Estate Wagon
1965-1967	Buick Gran Sport
1970-1972	Buick GS
1968-1969	Buick GS 350
1968-1969	Buick GS 400
1970-1972	Buick GS 455
1960-1963	Buick Invicta
1960-1973	Buick LeSabre
1977-1979	Buick Opel
1973	Buick Regal
1963-1973	Buick Riviera
1961-1972	Buick Skylark
1961-1969	Buick Special
1964-1972	Buick Sportwagon
1963-1970	Buick Wildcat
1965-1973	Cadillac Calais
1960-1974	Cadillac DeVille
1960-1973	Cadillac Eldorado
1965-1974	Cadillac Fleetwood
1960-1964	Cadillac Series 60 Fleetwood
1960-1964	Cadillac Series 62
1960-1964	Cadillac Series 75 Fleetwood
1961-1974	Chevrolet Bel Air
1961-1972	Chevrolet Biscayne
1969-1973	Chevrolet Blazer
1969-1972	Chevrolet Brookwood
1961-1974	Chevrolet C10 Pickup
1967-1974	Chevrolet C10 Suburban
1961-1974	Chevrolet C20 Pickup
1967-1974	Chevrolet C20 Suburban
1961-1974	Chevrolet C30 Pickup
1967-1974	Chevrolet Camaro
1966-1976	Chevrolet Caprice
1964-1973	Chevrolet Chevelle
1962-1968	Chevrolet Chevy II
1961-1974	Chevrolet Corvette
1964-1974	Chevrolet El Camino
1964-1974	Chevrolet G10 Van
1967-1974	Chevrolet G20 Van
1970-1974	Chevrolet G30 Van
1961-1974	Chevrolet Impala
1961-1974	Chevrolet K10 Pickup
1967-1972	Chevrolet K10 Suburban
1961-1974	Chevrolet K20 Pickup
1967-1973	Chevrolet K20 Suburban

Attributes
ASIN	B000182BDK
Brand	MSD, MSD
California Proposition 65	WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Category	Ignition, Ignition
Country of Origin (Primary)	CN
Emission Code	1, 1, Legal US
GTIN	00085132082025
Harmonized Tariff Code (Schedule B)	8511300080
Hazardous Material Code	N
Inductance	8 mH, 8 mH
Life Cycle Status Code	Available to Order
Maximum Voltage	45000, 45,000 Volts
NAFTA Preference Criterion Code	B
Peak Current	140 mA, 140 mA
Primary Resistance	.700 ohms, .7 OHMs
Product Type	Coil, Coil
SDR Required Flag	N
Sale Category	Ignition
Secondary Resistance	4.5K ohms, 4.5K OHMs
Series	Blaster Performance Coils
Spark Duration	350 uS, 350 uS
Sub Category	Ignition Coil
Subcategory	Coils and Parts
Turns Ratio	100:1, 4.167361111111111
Warning	California Proposition 65, California Proposition 65
Warranty	Limited 1 Year Warranty, Manufacturer's Limited 1 Year Warranty
Warranty Time	12
Weight	N/A, N/A
part type	Ignition Coil
