Four 40 Amp Relays
MSD relay modules are designed to be easily installed in most automotive electrical systems where a high amperage relay is needed. These relay modules are perfect use with high amperage electric fuel pumps and high CFM electric cooling fans. Each relay comes with a 40amp fuse, however lower amp fuses can be installed if required. The relay housing comes with a labeled lid that snaps into place providing a clean installation, and protecting the main power stud and triggers from contamination or accidental contact.
MSD relay modules are designed to be easily installed in most automotive electrical systems where a high amperage relay is needed. These relay modules are perfect use with high amperage electric fuel pumps and high CFM electric cooling fans. Each relay comes with a 40amp fuse, however lower amp fuses can be installed if required. The relay housing comes with a labeled lid that snaps into place providing a clean installation, and protecting the main power stud and triggers from contamination or accidental contact.
- 7V to 20V supply to fit a wide variety of applications
- Independent 40A outputs, to supply power to most aftermarket fuel pumps and electric fans
- Configurable single-wire activation with Ground (-) input or 12V (+) input, with removal of the Tie-Bar
- Removable cover for easy accessibility
- Low profile JCASE fuses provide ample protection in case of a short
- LED status indicators, show you which channel is triggered at a glance
| Attributes | |
| Brand | MSD |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category | Electrical, Lighting and Body |
| Country of Origin (Primary) | US |
| Emission Code | 5, 5 |
| GTIN | 00090127297049 |
| Harmonized Tariff Code (Schedule B) | 8409915085 |
| Hazardous Material Code | N |
| Life Cycle Status Code | Available to Order |
| NAFTA Preference Criterion Code | B |
| Product Type | Relays, Relays |
| SDR Required Flag | N |
| Sale Category | Electrical |
| Sub Category | Control Modules |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 1 Year Warranty, Manufacturer's Limited 1 Year Warranty |
| part type | Relay Control Module |
MSD Performance 7566-4 MSD 4 Channel Relay Module
Product Information
- Brand: MSD Performance
- Product Number: 7566-4
