Riding the dots! This one set the standard for programmable ignition control.
If you're a consummate engine tuner and know how to take advantage of minute changes in timing during a quarter-mile pass, then the Programmable Digital-7 Plus is the ignition for you! All of the standard programmable features such as Individual Cylinder Management, Step Retards, Rev Limits, Shift Points, and more are included in the Plus version but you also get more. Much, much more.
If you're a consummate engine tuner and know how to take advantage of minute changes in timing during a quarter-mile pass, then the Programmable Digital-7 Plus is the ignition for you! All of the standard programmable features such as Individual Cylinder Management, Step Retards, Rev Limits, Shift Points, and more are included in the Plus version but you also get more. Much, much more.
- Stage retards can be set to ramp the timing.
- Select the rpm limiter value in rpm/seconds.
- Automatic magnetic pickup compensation for crank triggers or distributor pick- ups.
- Program your engine's firing order for ease of setting the cylinder-to-cylinder timing.
- 12,500 RPM with 14.4 Volts
- Updated X-Y plots with interpolation for smooth changes.
- 12-18 Volts, Negative Ground
- Output to activate a device through rpm, time or pressure inputs.
- Program an rpm limit that is ramped in during the launch.
- 1.1 Amp per 1,000 RPM
- An upgraded micro- controller runs at 40MHz enabling timing accuracy within 0.1 degrees and +/-1 rpm at up to 10,000 rpm!
- View all ignition events in a new Launch History window including the retard sum, manifold pressure, rpm, shift points and more.
- There is a cam sync output for fuel controllers or data acquisition.
- Map a complete timing curve for every gear.
- Acquire 20 seconds of run data including two seconds prior to launch.
- Vacuum advance and boost retard is selectable through a MAP sensor.
| Attributes | |
| ASIN | B000630D30 |
| Brand | MSD, MSD |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category | Ignition, Ignition |
| Country of Origin (Primary) | US |
| Current Draw | 1.1 Amp per 1000 RPM, 1.1 Amp per 1,000 RPM |
| Emission Code | 4, 4, Off Road |
| Harmonized Tariff Code (Schedule B) | 8511804000 |
| Hazardous Material Code | N |
| Life Cycle Status Code | Available to Order |
| Maximum RPM | 12,500 |
| NAFTA Preference Criterion Code | B |
| part type | Ignition Control Module |
| Primary Voltage | 535, 535 Volts |
| Product Type | Ignition Box, Ignition Box |
| RPM | 12500 |
| RPM Range | 12,500 RPM with 14.4 Volts |
| Sale Category | Ignition |
| SDR Required Flag | N |
| Secondary Voltage | 40000, 40,000 Volts |
| Series | Drag Racing Ignitions |
| Spark Duration | 20 Degree Crankshaft Rotation |
| Spark Energy | 190 mJ per spark |
| Spark Energy (mJ per spark) | 190 |
| Spark Series Duration | 20 Degree Crankshaft Rotation, 20 Degree Crankshaft Rotation |
| Sub Category | Control Modules |
| Subcategory | Racing Electronics |
| Voltage | 12-18 V; Negative Ground |
| Voltage Required | 12-18 Volts, Negative Ground, 12-18 |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 1 Year Warranty, Manufacturer's Limited 1 Year Warranty |
| Warranty Time | 12 |
| Weight and Size | 3 lbs.,9.5"L x 4.5"W x 2.2"H, 3 lbs., 9.5L x 4.5W x 2.2H |
| GTIN | 00085132075317 |
