Compact design - full MSD power.
The Ultra 6A Series feature a capacitive discharge ignition design. The majority of stock ignition systems are inductive ignitions. In an inductive ignition, the coil must store and step up the voltage to maximum strength in between each firing. At higher rpm, since there is less time to charge the coil to full capacity, the voltage falls short of reaching maximum energy which results in a loss of power or top end miss.
The Ultra 6A Series feature a capacitive discharge ignition design. The majority of stock ignition systems are inductive ignitions. In an inductive ignition, the coil must store and step up the voltage to maximum strength in between each firing. At higher rpm, since there is less time to charge the coil to full capacity, the voltage falls short of reaching maximum energy which results in a loss of power or top end miss.
- Plug and Play upgrade to current installations with a 6201, MSD 6A
- Consistently high spark energy of 135mJ to 150mJ for every firing, from idle to redline rpm
- Easily installs on 4, 6, 8-cylinder engines with distributors
- Operates on most 7 to 28-volt electrical systems
- Connects to points and magnetic pickups
- Fully protected against an open coil, shorted coil & open load
- Compact design - full MSD power
- Quickens throttle response & improves starting
- Tach Output to drive an external Tachometer
- New processor and board design provide a highly efficient ignition, minimal heat and max spark energy with less current draw
- 60% smaller and 50% lighter than the MSD Digital 6A (688 grams vs 344 grams)
- High rpm operation and maximum output using the Blaster HVC, PN 8252 or HVC II, PN 8253
- Powerful capacitive discharge of multiple sparks improves performance, and ensure complete combustion
Information:
CARB EO: D-40-43| Attributes | |
| Brand | MSD |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category | Ignition |
| Color | Black, Black |
| Country of Origin (Primary) | US |
| Current Draw | 1.1 Amp per 1,000 RPM, 1.1 Amp per 1,000 RPM |
| Emission Code | 4, 3, Off Road |
| Features | No Rev Limiter, No Rev Limiter |
| GTIN | 00090127145296 |
| Harmonized Tariff Code (Schedule B) | 8511908000 |
| Hazardous Material Code | N |
| Ignition Type | Performance |
| Life Cycle Status Code | Available to Order |
| NAFTA Preference Criterion Code | B |
| Primary Voltage | 520-540 Volts, 520-540 Volts |
| Product Type | Digital 6A Ignition Control Box, Digital 6A Ignition Control Box |
| RPM | 15000 |
| RPM Range | 15,000 RPM with 14.4 Volts, 15,000 RPM with 14.4 Volts |
| SDR Required Flag | N |
| Sale Category | Ignition |
| Secondary Voltage | 45,000 Volts, 45,000 Volts |
| Spark Energy | 135mJ - 150mJ Per Spark, 135mJ - 150mJ Per Spark |
| Sub Category | Control Modules, Control Modules |
| Voltage Required | 12-15 Volts, 7 Volt Start, 12-15 Volts, 7 Volt Start |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 1 Year Warranty, Manufacturer's Limited 1 Year Warranty |
| Weight and Size | 3.3" x 3.8" - 344 grams, 3.3" x 3.8" - 344 grams |
| part type | Ignition Control Module |
MSD Performance 62023 Ultra 6A Ignition Box
Product Information
- Brand: MSD Performance
- Product Number: 62023
