Compatible with 4, 6, or 8 Cylinder Engines - Built-in LED for System Checks
A sealed, locking connector keeps the minimal wiring of the 6A tidy for a clean installation in all applications. It can be run on 4, 6 and 8 cylinder engines with a 12 volt negative ground electrical system and can be triggered with breaker points, an electronic amplifier or magnetic pickups.
A sealed, locking connector keeps the minimal wiring of the 6A tidy for a clean installation in all applications. It can be run on 4, 6 and 8 cylinder engines with a 12 volt negative ground electrical system and can be triggered with breaker points, an electronic amplifier or magnetic pickups.
- Easy Starts
- Smooth Idle
- Quick throttle response
- Built-in LED for system checks
- Full, capacitive discharge ignition power throughout the RPM range
- Compatible with 4, 6 or 8 - cylinder engines
- Tach output wire
- Sealed, locking connector
Information:
CARB EO: D-40-43| Attributes | |
| ASIN | B004EG5D08 |
| Brand | MSD, MSD |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category | Ignition, Ignition |
| Color | Red, Red |
| Connector Gender | Female |
| Connector Quantity | 1 |
| Country of Origin (Primary) | CN |
| Current Draw | .7 Amp per 1000 RPM, .7 Amp per 1,000 RPM |
| Emission Code | 1, 1, Legal US |
| Features | No Rev Limiter, No Rev Limiter |
| GTIN | 00085132062010 |
| Grade Type | Performance |
| Harmonized Tariff Code (Schedule B) | 8511804000 |
| Hazardous Material Code | N |
| Height | 1.825 |
| Ignition Type | Performance |
| Length | 8 |
| Life Cycle Status Code | Available to Order |
| Mount Type | Surface Mount |
| Mounting Hardware Included | Yes |
| NAFTA Preference Criterion Code | B |
| Primary Voltage | 520-540, 520-540 Volts |
| Product Type | Digital 6A Ignition Control Box, Digital 6A Ignition Control Box |
| RPM | 15000 |
| RPM Range | 15,000 RPM with 14.4 Volts, 15,000 RPM with 14.4 Volts |
| SDR Required Flag | N |
| Sale Category | Ignition |
| Secondary Voltage | 45000, 45,000 Volts |
| Series | 6-Series Ignitions |
| Spark Duration | 20 Degree Crankshaft Rotation |
| Spark Energy | 135-145 mJ per spark, 135-145 mJ per spark |
| Sub Category | Control Modules, Control Modules |
| Subcategory | Ignition Boxes |
| Terminal Gender | Male |
| Terminal Quantity | 12 |
| Voltage | 12-15 V; 7 V Start |
| Voltage Required | 12-15 Volts, 7 Volt Start, 12-15 Volts, 7 Volt Start |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 1 Year Warranty, Manufacturer's Limited 1 Year Warranty |
| Warranty Time | 12 |
| Weight and Size | 1.7 lbs., 8"L x 4"W x 1.825"H, 1.7 lbs., 8"L x 4"W x 1.825"H |
| Width | 4 |
| part type | Ignition Control Module |
MSD Performance 6201 MSD Digital 6A Ignition Control - Red
Product Information
- Brand: MSD Performance
- Product Number: 6201
