DRIVE AXLE SHAFT FOR GM 8.875" (12 BOLT); AXLE LENGTH 29.5625"; 5 X 4.75 LUG PATTERN; 30 SPLINE; DUAL DRILLED FOR 7/16" PRESS-IN OR 1/2" THREADED STUDS
Motive Gear offers some of the toughest drive train components on the market today. If you are looking for the largest line of performance ring and pinion gear options available with gear sets in a wide range of ratios for nearly every application, both on and off-road, check out Motive Gear. Motive Gear products can be found in the winner's circle at racing events worldwide. The superior quality of Motive Gear components is the result of years of racing development, outstanding design and state-of-the-art manufacturing methods. Extensive testing is performed on all products by our in-house engineers.
Information:
AXLE GM8.875" 30SPL 29.56" 5 LUG
Application Summary:
| Year |
Make/Model |
| 1967-1969 |
Chevrolet Camaro |
| 1965-1967 |
Chevrolet Chevelle |
| 1968 |
Chevrolet Chevy II |
| Attributes |
| App/Model |
GM 8.875 Car (12-Bolt Car) |
| ASIN |
B005TDNH9Y |
| Axle Bolt Hole Diameter |
.4375 Press-In, .4375 Press-In, .5 Threaded, .5 Threaded, .4375 Press-In, .5 Threaded |
| Axle Length |
29.5625 |
| Axle Material |
1541 Manganese |
| Axle Type |
GM 8.875 in. |
| California Proposition 65 |
WARNING: Cancer - www.P65Warnings.ca.gov |
| Country of Origin (Primary) |
IN |
| Differential Case Design Type |
GM 8.875 Car, GM 8.875 Car |
| Emission Code |
Legal US |
| Harmonized Tariff Code (Schedule B) |
8708504110 |
| Hazardous Material Code |
N |
| Inboard Spline Quantity |
30, 30 |
| Life Cycle Status Code |
Available to Order |
| NAFTA Preference Criterion Code |
B |
| Outboard Spline Quantity |
30 |
| Position |
Rear |
| SDR Required Flag |
N |
| Shaft Length |
29.5625 |
| Shaft Material |
1541 Manganese |
| Side |
Left (Driver), Right (Passenger) |
| Taxonomy |
Differential LD, Axle Shafts, GM 8.875 Car |
| Taxonomy A |
LD Differential, LD Differential |
| Taxonomy B |
Axle Shafts, Axle Shafts |
| Taxonomy C |
Axles - Rear, Axles - Rear |
| Taxonomy D |
Left, Right, Left (Driver), Right (Passenger) |
| Wheel Bolt Pattern Size |
5 x 4.75, 5 x 4.75 |
| GTIN |
00698231339046 |
