(5) Included Sensors
The boosted kit replaces the GM 1 BAR MAP sensor with a 3.5 BAR stainless steel sensor and the single 0-100 PSI pressure sensor is upgraded to two 0-200 pressure sensors.
The boosted kit replaces the GM 1 BAR MAP sensor with a 3.5 BAR stainless steel sensor and the single 0-100 PSI pressure sensor is upgraded to two 0-200 pressure sensors.
- (1) 534-10 Coolant Temperature Sensor
- (1) 534-20 Intake Air Temperature Sensor
- (2) 554-103 Pressure Sensor (0-200 PSI)
- (1) 554-134 Pressure Sensor (3.5 Bar)
| Attributes | |
| 534-10 Coolant Temperature Sensor | Brass, Male Female |
| 534-20 Intake Air Temperature Sensor | Brass, Male Female |
| 554-103 Pressure Sensor | Male Female, Performance |
| 554-134 Pressure Sensor | Male Female, Performance |
| Brand | Holley EFI |
| Category | Air and Fuel Delivery |
| Country of Origin (Primary) | US |
| Emission Code | 5 |
| GTIN | 00090127965153 |
| Grade Type | Performance |
| Harmonized Tariff Code (Schedule B) | 8409915085 |
| Hazardous Material Code | N |
| Life Cycle Status Code | Available to Order |
| Maximum Pressure Rating | 200 |
| Maximum Pressure Reading | 3.5 |
| Mounting Bracket Included | No |
| Mounting Hardware Included | No |
| Mounting Type | Threaded |
| NAFTA Preference Criterion Code | A |
| SDR Required Flag | N |
| Terminal Type | Blade |
| Thread Size | 3/8" NPT |
| Wiring Harness Included | No |
Holley EFI 554-203 Boosted Sensor Kit
Product Information
- Brand: Holley EFI
- Product Number: 554-203
