6-Bolt Flange Dual 255 LPH Drop-In EFI
***Supports up to 1100 EFI or 1400 Carb HP (@ 60 PSI at 13.5 Volts / 16.9 AMP Draw)
  • Update your fuel cell to EFI the easy way!
  • Designed to drop right into your existing 6 bolt flange fuel cell
  • Billet top flange housing includes an 8AN inlet and 10AN outlet port and a fuel filler cap
  • Module with Dual 255 LPH fuel pumps configurations
  • The pump depth is fully adjustable for fitment in the most popular cell sizes 7.5”-12” deep.
  • Supports up to 1100 EFI or 1400 Carb HP (@ 60 PSI at 13.5 Volts / 16.9 AMP Draw)

Information:

Fill cap thread is 1 1/2"-12
Attributes
Application Universal
Average Flow Rating 510
Brand Holley
Category EFI Fuel Pumps
Country of Origin (Primary) US
Emission Code 5
Flange Style 6 Bolt
Free Flow GPH 132
Free Flow LPH Dual 255
Fuel Type Gasoline, E85
GTIN 00090127029596
Harmonized Tariff Code (Schedule B) 8409915085
Hazardous Material Code N
Height Adjustable
Inlet Quantity One
Inlet Size 8 AN
Life Cycle Status Code Available to Order
Max Psi 87
NAFTA Preference Criterion Code B
Outlet Quantity One
Outlet Size 10 AN
Product Type Fuel Pump
SDR Required Flag N
Single Or Dual Pump Dual
Warning California Proposition 65
Warranty Manufacturer's Limited 90 Day Warranty
