Fits GM 6 bolt LS Engines with T-56 Transmission
This Kit includes all the hardware and components needed for a complete clutch install on a 6-bolt crank LS engine using a T-56 transmission. A 12-inch organic disc with a 6 spring helix sprung hub provides the superior grip needed for the strip, while the matched diaphragm style pressure plate provides a pedal feel comfortable enough for the street. This provides 30% more clamping pressure and transmits that through a Billet steel flywheel.
This Kit includes all the hardware and components needed for a complete clutch install on a 6-bolt crank LS engine using a T-56 transmission. A 12-inch organic disc with a 6 spring helix sprung hub provides the superior grip needed for the strip, while the matched diaphragm style pressure plate provides a pedal feel comfortable enough for the street. This provides 30% more clamping pressure and transmits that through a Billet steel flywheel.
- Includes Pressure Plate, Disk, Flywheel, Alignment Tool, Pilot Bearing, Pressure Plate Bolts, Flywheel Bolts and Hydraulic release bearing (hydraulic release bearing to transmission bolts not included)
- 12-inch Organic Single Disc Clutch with 1-1/8-inch 26 Spline Hub for LS Engines with 6 Bolt Crankshaft
- 6-Bolt Billet Steel Flywheel provides strength and a fresh, new foundation for the clutch
- Street/Strip Clutch Kit Provides Excellent Holding Strength with a Smooth Daily Driver Pedal Feel
- Designed for Power Levels up to 550 Naturally Aspirated Horsepower
Information:
Allow 500 miles for clutch break in period| Attributes | |
| Alignment Tool Included | Yes |
| Brand | Holley, Holley |
| Cable Included | No |
| California Proposition 65 | No |
| Category | Transmission |
| Country of Origin (Primary) | US |
| Disc Diameter | 12, 12 |
| Disc Material | Organic |
| Disc Style | Spring Hub, Spring Hub |
| Disc Type Sprung Solid | Sprung |
| Emission Code | 5, 5 |
| Engine | GM Gen III/IV (LS), GM Gen III/IV (LS) |
| Engine Make | GM, GM |
| Flywheel Material | Billet Steel, Billet Steel |
| Grade Type | Performance |
| Grease Included | No |
| Hardware | Steel, Steel |
| Harmonized Tariff Code (Schedule B) | 8708930000 |
| Hazardous Material Code | N |
| Input Shaft Diameter | 1-1/8 in., 1-1/8 in. |
| Input Spline | 26, 26 |
| Input Spline Quantity | 26 |
| Life Cycle Status Code | Available to Order |
| Mounting Hardware Included | Yes |
| NAFTA Preference Criterion Code | B |
| New Or Remanufactured Clutch | New, New |
| part type | Transmission Clutch and Flywheel Kit |
| PILOT BEARING | Roller, Roller |
| Pilot Bushing Included | Yes |
| Pressure Plate Bolts Included | Yes |
| Pressure Plate Style | Diaphragm, Diaphragm |
| Product Type | Clutch Installation Kit, Clutch Installation Kit |
| RELEASE BEARING | Hydraulic, Hydraulic |
| Release Bearing Included | Yes |
| Sale Category | Transmission and Drivetrain |
| SDR Required Flag | N |
| Sub Category | Transmission Components |
| Transmission | T56 GM, T56 Magnum GM |
| Warning | California Proposition 65, California Proposition 65 |
| GTIN | 00090127130582 |
