Street/Strip Carbureted Applications Compatible with Gasoline Only
The world famous Red®, Blue® and Black® fuel pumps are the most recognized performance pumps of all times. They have been powering racing legends and street enthusiasts alike since the early 70's. Their time proven rotor/vane design is known to get the job done in an affordable package.
- Tumble polished billet look
- Repair kits are readily available
- Can be serviced from the pump end
- Lower housing casting designed for enhanced fuel flow
- Not compatible with alcohol or methanol fuels
- Use of safety shut-off switch, P/N 12-810, strongly recommended
- Maximum pressure is 7 psi
- Motor draws 2 amps current
- Relay kit P/N 12-753 & 7 1/2 amp fuse recommended
- Constant fuel flow with no pulsation
- Improved design for street/strip applications
- Flows 97 GPH (free flow)
- Not designed to be used on aircraft of any type.
- Distinctive “Red” logo
- Flows 71 GPH at 4 psi
- regulator is not required
- Has externally accessible pressure relief valve (max 7 psi)
- Rotor/vane pump design is more tolerant of contaminated fuels
- Weighs only 2.88 lbs
- Not designed or recommended for use with fuel injection systems
- Includes mounting bracket
Information:
Should be mounted below the fuel level of the tank for a good gravity feed on the inlet side. Relay kit P/N 12-753 recommended. These are to be used with 12 volt systems only.
Application Summary:
| Year |
Make/Model |
| The |
world famous Red® |
| Blue® |
and Black® fuel pumps are the most recognized performance pumps of all times. They have been powering racing legends and street enthusiasts alike since the early 70ft.s. Their time proven rotor/vane design is known to get the job done in an affordable package. |
| Attributes |
| ASIN |
B00029JC5S |
| Application |
Universal, Universal |
| Ball Material |
Silver |
| Body Color |
Silver |
| Bracket Color |
Silver, Silver |
| Brand |
Holley, Holley |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category |
Air and Fuel Delivery |
| Country of Origin (Primary) |
US |
| Emission Code |
5, 5 |
| Free Flow GPH |
97, 97 |
| Free Flow LPH |
367, 367 |
| Fuel System |
Carbureted, Carbureted |
| Fuel System Type |
Carbureted |
| Fuel Type |
Gasoline, Gasoline |
| Fully Open |
367 |
| GTIN |
00090127484289 |
| Harmonized Tariff Code (Schedule B) |
8413309000 |
| Hazardous Material Code |
N |
| Housing Color |
Silver |
| Inlet Fitting Thread Size |
3/8 |
| Inlet Size |
0.375 in. NPT, 3/8 inch NPT |
| Life Cycle Status Code |
Available to Order |
| Material |
Aluminum, Aluminum |
| Motor Finish |
Silver, Silver |
| NAFTA Preference Criterion Code |
B |
| Outlet Fitting Thread Size |
3/8 |
| Outlet Size |
0.375 in. NPT, 3/8 inch NPT |
| Product Type |
Fuel Pump, Fuel Pump |
| Pump Body Color |
Silver, Silver |
| SDR Required Flag |
N |
| Sale Category |
Air and Fuel Delivery |
| Sub Category |
Fuel Pumps and Related Components |
| Warning |
California Proposition 65, California Proposition 65 |
| Warranty |
Limited 90 Day, Manufacturer's Limited 90 Day Warranty |
| part type |
Electric Fuel Pump |
