Street/Strip Carbureted Applications
Compatible with Gasoline, Alcohol or E85
The chrome motor and trick powder coated bracket match the mil-spec hard anodized base for unmatched beauty and durability. While these pumps have the capability to feed stout race engines, they are equally at home on the street due to their design and construction techniques.
- Gerotor design for smooth operation and durability
- Not designed for use on aircraft of any type.
- 3/8" NPT inlet & outlet fittings
- Black mil-spec nickel PTFE hard anodized billet base
- Show quality chrome 12v motor
- Profiled black powdercoated mounting bracket
- Laser engraved Holley logo & inlet/outlet markings
- Less noise than traditional vane pumps
- 6 1/4" tall
- Compatible with gasoline or alcohol
- Relay kit P/N 12-753 recommended
- Flows 125 GPH free flow
- Flows 110 GPH at 7 psi
- Powers engines from stock all the way up to 700 horsepower (Gasoline)
Information:
Should be mounted below the fuel level of the tank for a good gravity feed on the inlet side. Relay kit P/N 12-753 recommended. These should be used with 12 volt systems only.
Application Summary:
| Year |
Make/Model |
| Looking |
for a fuel pump that is quiet |
| powerful |
and dependable? Look at the Holley HP 125 and HP 150 series fuel pumps. The exclusive gerotor gearset quietly and efficiently pumps the fuel without the noise of traditional vane pumps. The chrome motor and trick powder coated bracket match the mil-spec hard anodized base for unmatched beauty and durability. While these pumps have the capability to feed stout race engines |
| they |
are equally at home on the street due to their design and construction techniques. |
| Attributes |
| Application |
Universal, Universal |
| ASIN |
B000M294RQ |
| Ball Material |
Chrome |
| Body Color |
Black Anodized |
| Bracket Color |
Black, Black |
| Brand |
Holley, Holley |
| California Proposition 65 |
No |
| Category |
Air and Fuel Delivery |
| Color |
Silver |
| Country of Origin (Primary) |
US |
| Emission Code |
5, 5 |
| Finish |
Anodized |
| Free Flow GPH |
125, 125 |
| Free Flow LPH |
473, 473 |
| Fuel Delivery Type |
Carburetor, Carburetor |
| Fuel Sending Unit Included |
No, No |
| Fuel System |
Carbureted, Carbureted |
| Fuel System Type |
Carbureted |
| Fuel Type |
Alcohol, E85, Gasoline, Methanol |
| Fully Open |
473 |
| Gasket Or Seal Included |
No, No |
| Grade Type |
Performance, Performance |
| Harmonized Tariff Code (Schedule B) |
8413309000 |
| Hazardous Material Code |
N |
| Housing Color |
Black Anodized |
| Inlet Fitting Thread Size |
3/8, 3/8 |
| Inlet Size |
0.375 in. NPT, 3/8 inch NPT |
| Inlet Type |
NPT, NPT |
| Internal Or External |
External, External |
| Life Cycle Status Code |
Available to Order |
| Material |
Aluminum, Aluminum |
| Maximum Flow Rating |
125, 125 |
| Maximum Pressure |
7, 7 |
| Motor Finish |
Chrome, Chrome |
| Mounting Hardware Included |
No, No |
| NAFTA Preference Criterion Code |
B |
| Negative Ground |
Yes, Yes |
| Outlet Fitting Thread Size |
3/8, 3/8 |
| Outlet Quantity |
1, 1 |
| Outlet Size |
0.375 in. NPT, 3/8 inch NPT |
| Outlet Type |
NPT, NPT |
| part type |
Electric Fuel Pump, Electric Fuel Pump |
| Product Type |
Fuel Pump, Fuel Pump |
| Pump Body Color |
Black Anodized, Black Anodized |
| Regulator Included |
No, No |
| Sale Category |
Air and Fuel Delivery |
| SDR Required Flag |
N |
| Strainer Included |
No, No |
| Terminal Quantity |
2 |
| Universal Or Specific Fit |
Universal, Universal |
| Voltage |
12, 12 |
| Warning |
California Proposition 65, California Proposition 65 |
| Warranty |
Limited 90 Day, Manufacturer's Limited 90 Day Warranty |
| Wire Quantity |
2, 2 |
| Wiring Harness Included |
No, No |
| GTIN |
00090127606209 |
