REGULATOR/DAMPER, EXTENDED RANGE 40-100PSI
Fuel pulse dampers act in tandem with the fuel pressure regulator to further control the fuel pressure in an EFI system. They act to smooth out the pressure pulsations caused by the injectors opening and closing as well as the fuel pump operating. These pulsations happen so quickly that in many cases they can't be identified with an analog gauge but can cause issues with fuel delivery to the engine.
Fuel pulse dampers act in tandem with the fuel pressure regulator to further control the fuel pressure in an EFI system. They act to smooth out the pressure pulsations caused by the injectors opening and closing as well as the fuel pump operating. These pulsations happen so quickly that in many cases they can't be identified with an analog gauge but can cause issues with fuel delivery to the engine.
- Engineered to stabilize pressure pulsations caused by the injectors opening, ideal for applications with large fuel injectors and high volume fuel pumps
- Compatible with any fuel -- full anodized billet aluminum construction with stainless steel springs and fluorosilicone diaphragm
- Fittings included for damper/regulator’s and direct mount dampers
- 1/8" NPT port on body of damper/regulators and in-line dampers for easy installation of mechanical pressure gauge or pressure transducer
- Vacuum fitting and one foot of hose included with all dampers for vacuum referencing
- Assembled and tested in the USA
| Attributes | |
| Brand | Holley, Holley |
| Category | Air and Fuel Delivery |
| Country of Origin (Primary) | US |
| Emission Code | 3, 3, Off Road |
| Finish | Anodized Black, Anodized Black |
| Fuel Type | Gasoline / Ethanol / Methanol / E85, Gasoline / Ethanol / Methanol / E85 |
| GTIN | 00090127475638 |
| Harmonized Tariff Code (Schedule B) | 8409918000 |
| Hazardous Material Code | N |
| Inlet / Outlet Size | 3/4-16 Female O-Ring (AN 8), 3/4-16 Female O-Ring (AN 8) |
| Inlet Port Diameter | 8 AN ORB, 8 AN ORB |
| Life Cycle Status Code | Available to Order |
| Outlet Port Diameter | 8 AN ORB, 8 AN ORB |
| Pressure Range | 40-100 PSI, 40-100 PSI |
| Product Type | Fuel Pressure Regulator/ Damper, Fuel Pressure Regulator/ Damper |
| SDR Required Flag | N |
| Style | Billet Aluminum, Billet Aluminum |
| Sub Category | Carburetion |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 90 Day, Manufacturer's Limited 90 Day Warranty |
| part type | Fuel Pressure Regulator |
NEW! Holley 12-1001 HOLLEY FUEL REGULATOR/DAMPER
Product Information
- Brand: Holley
- Product Number: 12-1001
