FEL-PRO 1094 Embossed steel shim w/coating Engine Cylinder Head Gasket
Fel-Pro(R) gaskets are specifically designed for the repair environment to deliver a reliable seal on even the most troublesome applications. Designed for imperfect sealing surfaces and manufactured with proprietary materials, you can count on Fel-Pro for innovative sealing solutions for the real-world repair environment.
- Fel-Pro Performance head gaskets accommodate the high cylinder pressures and cylinder head movement associated with performance engines.
- Embossed steel shim w/coating
- Not intended for use in emission controlled vehicles.
Application Summary:
| Year |
Make/Model |
| GMP |
Perf. V8, 265 (4.3L), 283 (4.6L), 302 (4.9L), 307 (5.0L), 327 (5.3L), 350 (5.7L) |
| Embossed |
shim |
| Attributes |
| Alternate Part Number |
1094 |
| Application Notes |
Cast iron or aluminum heads - Used in Sportsman drag race and flat top piston oval track categories, Cast iron or aluminum heads - Used in Sportsman drag race and flat top piston oval track categories |
| Bore Size (in.) |
4.100, 4.100 |
| California Proposition 65 |
No |
| Combustion Chamber Volume (cc) |
3.20, 3.200 |
| Combustion Seal Design |
Embossed Steel Bead, Embossed Steel Bead |
| Country of Origin (Primary) |
US |
| Engine Displacement |
262, 265, 267, 283, 302, 305, 307, 327, 350, 262, 265, 267, 283, 302, 305, 307, 327, 350 |
| Engine Family |
Chevrolet V8 Small Block, Chevrolet V8 Small Block |
| GTIN |
00084113010941 |
| Harmonized Tariff Code (Schedule B) |
8484100000 |
| Hazardous Material Code |
N |
| Life Cycle Status Code |
Available to Order |
| Mfg. |
GM Performance, GM Performance |
| Product Notes |
Do not use on 400 Engs.; Do not use on aluminum blocks w/liners; No brinelling of aluminum heads, Do not use on 400 Engs.; Do not use on aluminum blocks w/liners; No brinelling of aluminum heads |
| SDR Required Flag |
N |
