CURT 14301 Class 4 Trailer Hitch, 2-Inch Receiver, Fits Select Chevrolet Silverado, GMC Sierra 1500
Whatever the next item is on your to-do list -- whether it's arriving at the jobsite before dawn or getting your travel trailer set up in time to see the sunset -- CURT class 4 trailer hitches offer greater towing power to let you Bring It. These custom receiver hitches are built to tackle bigger jobs and bolder adventures, all while giving you a custom fit for your vehicle. Class 4 hitches are available for a variety of makes and models, from pickup trucks and SUVs to full-size and commercial vans. This particular class 4 hitch fits certain years of the Chevy Silverado 1500, 1500 Classic or 1500 HD Classic and GMC Sierra 1500, 1500 Classic or 1500 HD Classic (to verify vehicle compatibility, see application info). It provides a weight carrying capacity of 10,000 lbs. GTW and 1,000 lbs. TW. It can also accept a weight distributing hitch, offering a maximum WD capacity of 12,000 lbs. and a WDTW of 1,200 lbs. CURT class 4 tow hitches are as much suited for work as they are for play. With their high load capacities, they are typically used for towing larger trailers, including everything from a double-axle utility trailer or livestock trailer to a full-length camper or large boat trailer (NOTE: Never exceed the lowest weight capacity of any towing component). All CURT class 4 receiver hitches come with a 2" receiver tube opening and all the necessary hardware for a complete installation. From light-duty to heavy-duty, every CURT custom hitch is engineered to be vehicle-specific, using actual vehicles to create the optimal design. We then combine high-strength steel, precise welding and a co-cured finish of liquid A-coat and durable black powder coat to provide you with a hitch you can depend on. To prove it, we test all our hitches in accordance with SAE J684 for safety.
- Rated to 10,000 lbs. gross trailer weight and 1,000 lbs. tongue weight
Information:
Compatible with weight distribution hitch (12,000 lbs. WD / 1,200 lbs. WDTW)
Application Summary:
| Year |
Make/Model |
| 2007-2018 |
Chevrolet Silverado 1500 |
| 2019 |
Chevrolet Silverado 1500 LD |
| 2007-2018 |
GMC Sierra 1500 |
| 2019 |
GMC Sierra 1500 Limited |
| Attributes |
| ASIN |
B001EOV3Q6 |
| Body Shape |
Square |
| Box Height in Inches - XA |
25, 25 |
| Box Length in Inches - XA |
41, 41 |
| Box Width in Inches - XA |
12, 12 |
| California Proposition 65 |
Yes |
| Class ID |
4, 4 |
| Container Volume Cubic Feet - XA |
0.00000 |
| Container Volume Cubic Meter - XA |
0.00000 |
| Country of Origin (Primary) |
US |
| Drilling Required |
No |
| Finish |
Gloss Black Powder Coat |
| Finish - XA |
GLOSS BLACK POWDER COAT, GLOSS BLACK POWDER COAT |
| GTIN |
00612314143016 |
| Gross Trailer Weight |
10000 lbs. |
| Gross Trailer Weight (lbs.) |
10000 |
| Harmonized Tariff Code (Schedule B) |
8708998180 |
| Hazardous Material Code |
N |
| Install Time |
30 Minutes |
| Item Class - XA |
MFH, MFH |
| Item Height - XA |
10.350, 0.000 |
| Item Length - XA |
41.375, 0.000 |
| Item Width - XA |
23.140, 0.000 |
| Life Cycle Status Code |
Available to Order |
| Long Description |
Class IV Trailer Hitch |
| Main Body Shape |
Square, Square |
| Master Case Height Inches - XA |
0.000 |
| Master Case Length Inches - XA |
0.000 |
| Master Case Volume Cubic Feet - XA |
0.00000 |
| Master Case Weight Lbs - XA |
0.000 |
| Master Case Width Inches - XA |
0.000 |
| Material - XA |
Carbon Steel |
| Mount Type Description - XA |
Blank |
| NAFTA Preference Criterion Code |
B |
| Pallet Qty - XA |
18.000 |
| Pallet Total Height Inches - XA |
0.000, 0.000 |
| Pallet Total Weight Per - XA |
0.000, 0.000 |
| Parcel Allowed - XA |
Yes, Yes |
| Position |
Rear |
| Price Code - XA |
49, 47 |
| Product Weight - XA |
52.000, 52.000 |
| Rate Class - XA |
70.0, 125.0 |
| Receiver Tube Size |
2 IN, 2.000 in. |
| Retail Height - XA |
13.000, 13.000 |
| Retail Length - XA |
42.000, 42.000 |
| Retail Width - XA |
27.000, 27.000 |
| SDR Required Flag |
N |
| Sales Family Code - XA |
HITCH, HITCH |
| Sales Family Description - XA |
HITCH, HITCH |
| Sales Group Description - XA |
CL 4, CL 4 |
| Shipping Weight - XA |
59.000, 59.000 |
| Side Application Type Description - XA |
Blank, Blank |
| Tariff 301 - XA |
No, No |
| Tongue Weight (TW) |
1,000 LB, 1,000 LB |
| Tongue Weight(TW) |
1,000 LB |
| Truckload Volume Cubic Feet - XA |
0.00000, 0.00000 |
| Visibility |
Concealed |
| WC Tongue Weight |
1000 |
| WD Tongue Weight |
1200 |
| Warranty |
Limited Lifetime Warranty (One-Year Finish, One-Year Parts), Limited Lifetime Warranty (One-Year Finish, One-Year Parts) |
| Weight Carrying Capacity |
10000 |
| Weight Carrying Capacity (WC) |
10,000 LB, 10,000 LB |
| Weight Carrying Capacity(WC) |
10,000 LB |
| Weight Distribution |
12000 |
| Weight Distribution (WD) |
12,000 LB, 12,000 LB |
| Weight Distribution Tongue Weight (WDTW) |
1,200 LB, 1,200 LB |
| Weight Distribution Tongue Weight(WDTW) |
1,200 LB |
| Weight Distribution(WD) |
12,000 LB |
